LH-TC Pneumatic Clamping Finger Gripper LT-PG2-380
LH-TC Pneumatic Clamping Finger Gripper LT-PG2-380 - Image 2

LH-TC Pneumatic Clamping Finger Gripper LT-PG2-380

Pneumatic gripper is one of end-effectors which takes compressed air as power to clamp or grab workpieces, can replace human hand, used to catch workpieces with different shapes, measurements, weights and materials, to combine grabbing force and grabbing stroke perfectly and then improve the stability of production process.

SKU: LT-PG2-380
Category: ,
Tags:

Description

LH-TC CLAMPING TECHNOLOGY

Technology highlights

Model Rules
For example：LT-PG2-125A-CFM-HT-DP LT-PG3-100B-OFM-HT-PP

Model：LT-PG2-380 series

  • Stroke per jaw: 45mm/60mm
  • Recommended gripping: 48-82.5kg
  • Weight: 26-32kg
  • Larger piston area design, greater gripping force
  • Multi-tooth guide rail design, precise gripping of various workpieces
