LH-TC Robotic Tool Changer LTC-0020E

LH-TC·Tool changer is a flexible device which can help single industrial robot match with more end-effectors, each robot side can match with more tool sides, increase robot production lines’ flexibility and use of robots. Widely used in end-of-arm-tools switching, such as spot welding torchs, end-effectors, grippers, press guns, deburring removal tools, visible tools, Ultrasonic welding…

Description

Model:LTC-0020E

Recommended payload ≤ 20kg.
Locking force: 2514N allowable moment: 58.6N·m (static) allowable torque: 80N·m (static).
12*M5 pneumatic port connection and 4 module mounting interfaces.
Suitable for assembly, handling, ultrasonic welding,etc.
With air pressure loss self-locking function, even if the air pressure in master plate cut off accidentally, master plate and tool plate will not be separate.
